SH C01 Single-Monitor Steel Articulating Monitor Mount

Product Category:	Articulating Monitor Arm
Rank:	Economy
Material:	Steel
Surface Finish:	Powder Coating
Color:	Matte Black
Dimensions:	114x148x548mm (4.5"x5.8"x21.6")
Fit Screen Size:	Suitable For Most 13" ~ 32" Screen
Fit Curved Monitor:	No
Screen Quantity:	1
Weight Capacity (per screen):	8kg (17.6lbs)
VESA Compatible:	75x75,100x100
Tilt Range:	+45° ~ -45°
Swivel Range:	+90° ~ -90°
Screen Rotation:	+180° ~ -180°
Pole Height:	443mm (17.4")
Installation:	Grommet,Clamp
Suggested Desktop Thickness:	Clamp?10-88mm, Grommet? 10-75mm (Clamp?0.39"-3.5", Grommet? 0.39"-3")
Quick Release VESA Plate:	Yes
Cable Management:	Yes
Anti-theft:	No
Accessory Kit Package:	Normal/Ziplock Polybag,Compartment Polybag

Made of quality steel construction, the SH C01 can instantly transform a desktop into an organized and spacious work area. The full-motion structure allows smooth and easy rotation and positioning in any direction so that the ideal viewing angle can be easily found. Monitor installation/removal is made easy using the detachable VESA plate. The monitor arm can firmly support monitors up to 32” and 8kg/17.5lbs. Installation is easy using the included clamp-on mount or through-desk grommet mount. Cable clips are included keeping wires neatly organized and safely out of the way.

Detachable VESA Plate Design: enables easy installation.

Freely Adjusting Height: for an optimal ergonomic position.

Cable Management: keep everything organized.

360° Rotary VESA Plate: for more viewing experience.

Two Mounting Options: both desk clamp and grommet are included.
